Product series
P10A
Applications
Construction Equipment Industrial Vehicles & Road Machines

MultiFaster 10 lines

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
6,3 & 12,5 1/4" & 1/2" 2P10A-10-A F C
Specs
5 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6659.5 g 14.68 lb

For more information contact us: [email protected]
10 10
6,3 & 12,5 1/4" & 1/2" 2P10A-10-B F C
Specs
5 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
10 10
6,3 & 12,5 1/4" & 1/2" 2P10A-A1-7-A FC
Specs
4 x Couplings 1/4":BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
3 x Couplings 1/2":BSPP 3/4" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
1 Electrical Contact :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6233 g 13.74 lb

For more information contact us: [email protected]
10 7 2
6,3 & 12,5 1/4" & 1/2" 3P10A-10-D FGC
Specs
5 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
10 10

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
6,3 & 12,5 1/4" & 1/2" 2P10A-10-A M C
Specs
5 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3354 g 7.39 lb

For more information contact us: [email protected]
10 10
6,3 & 12,5 1/4" & 1/2" 2P10A-A1-7-A MC
Specs
4 x Couplings 1/4":BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
3 x Couplings 1/2":BSPP 3/4" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
1 Electrical Contact :7 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2672.3 g 5.89 lb

For more information contact us: [email protected]
10 7 2
6,3 & 12,5 1/4" & 1/2" 3P10A-10-B M C
Specs
5 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
10 10
6,3 & 12,5 1/4" & 1/2" 3P10A-10-C MGC
Specs
5 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
5 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4539.8 g 10.01 lb

For more information contact us: [email protected]
10 10
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
04 6.3 1/4" 25 MPa 3625.943 psi 20 5.283 0.008 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
