Product series
PS08
Applications
Agriculture

MultiFaster 5 lines size 08 (1/2"), 1 line with electric connector.

Multifaster suitable for 4+1 lines size 08. The additional line could be either an electrical connector or an hydraulic coupling.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 1/2" 2PS08-1-4-12GFC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6038 g 13.31 lb

For more information contact us: [email protected]
5 4 1
12,5 1/2" 2PS08-1-4-2/2FC
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6020.5 g 13.27 lb

For more information contact us: [email protected]
5 4 1
12,5 1/2" 2PS08-4-2/22F C
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6060.5 g 13.36 lb

For more information contact us: [email protected]
5 4
12,5 1/2" new 2PS08-A-4-2/2FC
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Seals: NBR & PUR
Weight: 6050 g 13.34 lb
5 4 1

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 1/2" 2PS08-1-4-12GMC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2343.1 g 5.17 lb

For more information contact us: [email protected]
5 4 1
12,5 1/2" 2PS08-1-4-2/2MC
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :3 Pins
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2191.4 g 4.83 lb

For more information contact us: [email protected]
5 4 1
12,5 1/2" 2PS08-4-12G M C
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 2325 g 5.13 lb
5 4
12,5 1/2" 2PS08-4-2/22M C
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2229 g 4.91 lb

For more information contact us: [email protected]
5 4
12,5 1/2" 3PS08-1-4-12GMC
Specs
4 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Seals: NBR & PUR
5 4
12,5 1/2" new 3PS08-A-4-2/2MC
Specs
4 x Couplings 1/2":M22x1,5 MALE 15L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :7 Pins
Seals: NBR & PUR
Weight: 3400 g 7.5 lb
5 4 1
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
