Product series
PLK
Applications

MultiFaster for harvesting application, 2 lines size 06, 3 lines size 09.

PLK series Multifaster has been developed for harvesting applications. Interchangeable according to market driven standards. Two lines size 06, three lines size 09.

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
10 & 14,3 3/8" & 9/16" 3PLK-0-5-A F C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
1 x Coupling 9/16":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 9500 g 20.94 lb

For more information contact us: info@fastercouplings.com
6 5
10 & 14,3 3/8" & 9/16" 3PLK-0-5-B F C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
1 x Coupling 9/16":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 10170 g 22.42 lb
6 5 1

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
10 3/8" 3PLK-0-2-A M C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3471 g 7.65 lb

For more information contact us: info@fastercouplings.com
6 2
10 3/8" 3PLK-0-2-C M C
Specs
2 x Couplings 3/8":3/4"-16 UNF MALE ORFS - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: info@fastercouplings.com
6 2
10 & 14,3 3/8" & 9/16" 3PLK-0-5-A M C
Specs
3 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4700 g 10.36 lb

For more information contact us: info@fastercouplings.com
6 5
10 & 14,3 3/8" & 9/16" 3PLK-0-5-B M C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
1 x Coupling 9/16":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 4700 g 10.36 lb
6 5 1
10 & 14,3 3/8" & 9/16" 3PLK-0-4-A M C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
1 x Coupling 9/16":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Seals: NBR & PUR
6 4
10 & 14,3 3/8" & 9/16" 3PLK-0-5-C M C
Specs
2 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
3 x Couplings 9/16":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 4700 g 10.36 lb
6 5 1
14,3 9/16" 3PLK-0-2-B M C
Specs
1 x Coupling 9/16":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
1 x Coupling 9/16":1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate: 35 (l/min) at 0.2 MPa 9.246 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3304 g 7.28 lb

For more information contact us: info@fastercouplings.com
6 2
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
06 10 3/8" 25 MPa 3625.943 psi 20 5.283 0.02 100 MPa 14503.774 psi 69 MPa 10007.604 psi 88 MPa 12763.321 psi
09 14.3 9/16" 25 MPa 3625.943 psi 35 9.246 0.02 100 MPa 14503.774 psi 69 MPa 10007.604 psi 88 MPa 12763.321 psi
Material:
Cast Iron & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII)
Specifications:
Series Interchange: MARKET
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Male Half up to W.P.
