Product series
P808
Applications

MultiFaster 8 lines, size 08.

Female

Filter items
Units
PartNumber Details Housings Couplings Electrical Contacts
12,5 1/2" 2P808-8-12G FC
Specs
8 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6603 g 14.56 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-8-T F C
Specs
8 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6603 g 14.56 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-6-12G F C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6206.9 g 13.68 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-6-D F C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6217 g 13.71 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-6-D1 F C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6217 g 13.71 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-6-E F C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6300 g 13.89 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-8-12S FC
Specs
8 x Couplings 1/2":3/4"-16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6652.5 g 14.67 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-8-34S FC
Specs
8 x Couplings 1/2":1-1/16"-12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-8-34SHFC
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6710 g 14.79 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-8-E F C
Specs
8 x Couplings 1/2":M16x1,5 MALE 10L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6581 g 14.51 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-A-6-B F C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6251 g 13.78 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 2P808-A-6-B F S
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6251 g 13.78 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 2P808-A-6-C F C
Specs
6 x Couplings 1/2":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 6328 g 13.95 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 2P808-A-7-12GFC
Specs
7 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
1 Electrical Contact :7 Pins
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: info@fastercouplings.com
8 7 1

Male

Filter items
Units
PartNumber Specs Housings Couplings Electrical Contacts
12,5 1/2" 2P808-8-12G MC
Specs
8 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3431.8 g 7.57 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 3P808-8-12G MC
Specs
8 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5555.8 g 12.25 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-1-6-8BMJ
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2762 g 6.09 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 2P808-6-12G M C
Specs
6 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-6-8BC M C
Specs
6 x Couplings 1/2":13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 27 g 0.06 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 2P808-8-34S MC
Specs
8 x Couplings 1/2":1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3681 g 8.12 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 2P808-A-6-B M C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2776.7 g 6.12 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 2P808-A-7-12GMC
Specs
7 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
1 Electrical Contact :7 Pins
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3212.8 g 7.08 lb

For more information contact us: info@fastercouplings.com
8 7 1
12,5 1/2" 3P808-6-8BC M C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4183 g 9.22 lb

For more information contact us: info@fastercouplings.com
8 6
12,5 1/2" 3P808-8-A M C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3859 g 8.51 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 3P808-8-E M C
Specs
8 x Couplings 1/2":M16x1,5 MALE 10L - ISO 8434-1-L
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 5092.6 g 11.23 lb

For more information contact us: info@fastercouplings.com
8 8
12,5 1/2" 3P808-A-6-B M C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 4228.8 g 9.32 lb

For more information contact us: info@fastercouplings.com
8 6 1
12,5 1/2" 3P808-B-6-B M C
Specs
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: info@fastercouplings.com
8 6 2
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
08 12.5 1/2" 25 MPa 3625.943 psi 70 18.492 0.01 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
