Product series
P5065
Applications

MultiFaster 5 lines, 2 lines 06, 3 lines 04.

Female

Filter items
Units
PartNumber Details Housings Couplings
6,3 & 10 1/4" & 3/8" 2P5065-3-A F C
Specs
3 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3388 g 7.47 lb

For more information contact us: [email protected]
5 3
6,3 & 10 1/4" & 3/8" 2P5065-5-A F C
Specs
3 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3864 g 8.52 lb

For more information contact us: [email protected]
5 5
6,3 & 10 1/4" & 3/8" 2P5065-2-12G FC
Specs
2 x Couplings 3/8":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 2P5065-2-14G FC
Specs
2 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 2P5065-2-A F C
Specs
2 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3350.4 g 7.39 lb

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 2P5065-2-A F NH
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3550.4 g 7.83 lb

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 2P5065-3-A F NH
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3388 g 7.47 lb

For more information contact us: [email protected]
5 3
6,3 & 10 1/4" & 3/8" 2P5065-3-A1 F C
Specs
1 x Coupling 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3561 g 7.85 lb

For more information contact us: [email protected]
5 3
6,3 & 10 1/4" & 3/8" 2P5065-4-A F C
Specs
2 x Couplings 1/4":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3638 g 8.02 lb

For more information contact us: [email protected]
5 4
6,3 & 10 1/4" & 3/8" 2P5065-5-A F NH
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3864 g 8.52 lb

For more information contact us: [email protected]
5 5
6,3 & 10 1/4" & 3/8" 2P5065-5-F F C
Specs
3 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3055 g 6.74 lb

For more information contact us: [email protected]
5 5

Male

Filter items
Units
PartNumber Specs Housings Couplings
6,3 & 10 1/4" & 3/8" 3P5065-2-38S MC
Specs
2 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1392.3 g 3.07 lb

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 3P5065-2-A M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
5 2
6,3 & 10 1/4" & 3/8" 3P5065-3-A M C
Specs
3 x Couplings 1/4":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
5 3
6,3 & 10 1/4" & 3/8" 3P5065-3-C M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1608 g 3.55 lb

For more information contact us: [email protected]
5 3
6,3 & 10 1/4" & 3/8" 3P5065-4-A M C
Specs
2 x Couplings 3/8":9/16" - 18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
2 x Couplings 1/4":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1561 g 3.44 lb

For more information contact us: [email protected]
5 4
6,3 & 10 1/4" & 3/8" 3P5065-4-C M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1856 g 4.09 lb

For more information contact us: [email protected]
5 4
6,3 & 10 1/4" & 3/8" 3P5065-5-A M C
Specs
3 x Couplings 1/4":9/16"-18 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1630 g 3.59 lb

For more information contact us: [email protected]
5 5
6,3 & 10 1/4" & 3/8" 3P5065-5-A M NH
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1630.1 g 3.59 lb

For more information contact us: [email protected]
5 5
6,3 & 10 1/4" & 3/8" 3P5065-5-F M C
Specs
3 x Couplings 1/4":BSPP 1/4" FEMALE - ISO 1179-1
Flow Rate: 20 (l/min) at 0.2 MPa 5.283 (gal/min) at 0.2 MPa
2 x Couplings 3/8":BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1975 g 4.35 lb

For more information contact us: [email protected]
5 5
6,3 & 10 1/4" & 3/8" 3P5065-5-G M C
Specs
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2042 g 4.5 lb

For more information contact us: [email protected]
5 5
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
04 6.3 1/4" 25 MPa 3625.943 psi 20 5.283 0.008 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
06 10 3/8" 25 MPa 3625.943 psi 40 10.567 0.008 100 MPa 14503.774 psi 100 MPa 14503.774 psi 100 MPa 14503.774 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
