Product series
P406A
Applications
Agriculture Construction Equipment Vehicles & Road Machines

MultiFaster 4 lines, size 06.

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
10 3/8" 2P406A-4-2/18FC
Specs
4 x Couplings 3/8":M18x1,5 MALE 12L - ISO 8434-1-L
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 2986 g 6.58 lb

For more information contact us: [email protected]
4 4
10 3/8" 2P406A-4-A F C
Specs
4 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 3000 g 6.61 lb

For more information contact us: [email protected]
4 4

Male

Filter items
Units
PartNumber Specs Housings Couplings
10 3/8" 2P406A-4-2/18MC
Specs
4 x Couplings 3/8":M18x1,5 MALE 12L - ISO 8434-1-L
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1232.2 g 2.72 lb

For more information contact us: [email protected]
4 4
10 3/8" 3P406A-4-A M C
Specs
4 x Couplings 3/8":11/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR

For more information contact us: [email protected]
4 4
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
06 10 3/8" 25 MPa 3625.943 psi 40 10.567 0.008 100 MPa 14503.774 psi 100 MPa 14503.774 psi 110 MPa 15954.151 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
