Product series
MultiSlide
Applications
Construction Equipment

MultiFaster 2 lines (size 08) or 3 lines (2 lines size 08, 1 line size 06)

Configure your Multifaster

Female

Filter items
Units
PartNumber Details Housings Couplings
12,5 1/2" MSC208-2-12G F C
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
2 2
10 & 12,5 1/2" & 3/8" MSC3A-3-A F C
Specs
1 x Coupling 3/8":BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
3 3

Male

Filter items
Units
PartNumber Specs Housings Couplings
10 & 12,5 3/8" & 1/2" MSC3A-3-A M C
Specs
1 x Coupling 3/8":BSPP 3/8" FEMALE - ISO 1179-1
Flow Rate: 40 (l/min) at 0.2 MPa 10.567 (gal/min) at 0.2 MPa
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
3 3
12,5 1/2" MSC208-2-12G M C
Specs
2 x Couplings 1/2":BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate: 70 (l/min) at 0.2 MPa 18.492 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
2 2
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Male Burst pressure Female Burst pressure Male + Female Burst pressure
06 10 3/8" 35 MPa 5076.321 psi 40 10.567 0.008 140 MPa 20305.283 psi 140 MPa 20305.283 psi 140 MPa 20305.283 psi
08 12.5 1/2" 35 MPa 5076.321 psi 70 18.492 0.01 140 MPa 20305.283 psi 140 MPa 20305.283 psi 140 MPa 20305.283 psi
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
