Product series
P608
Applications
MultiFaster 6 lines, size 08.
Downloads
Data sheet
User Instruction
Configure your Multifaster
Items
Specs
Applications
Female
Male
Accessories
Female
Filter items
Units
Metric
Imperial
Size (mm)
12.5 mm
Size (mm)
Size (mm)
12.5 mm
Size (in)
1/2"
Size (in)
Size (in)
1/2"
PartNumber
Details
Housings
Couplings
Electrical Contacts
12,5
1/2"
|1/2|
2P608-1-5-12GFC
Specs
5 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :
3 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
5
1
12,5
1/2"
|1/2|
2P608-2-4-12GFC
Specs
4 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :
3 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
4
2
12,5
1/2"
|1/2|
2P608-4-12S F C
Specs
4 x Couplings 1/2":
3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
4475.6 g
9.87 lb
For more information contact us:
info@fastercouplings.com
6
4
12,5
1/2"
|1/2|
2P608-6-12G F C
Specs
6 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
4838.8 g
10.67 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-12S F C
Specs
6 x Couplings 1/2":
3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
3904.6 g
8.61 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-34S F C
Specs
6 x Couplings 1/2":
1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
5082.2 g
11.2 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-A-5-12GFC
Specs
5 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :
7 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
5
1
12,5
1/2"
|1/2|
2P608-B-4-C F C
Specs
4 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :
7 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
4
2
12,5
1/2"
|1/2|
3P608-6-12G F C
Specs
6 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
4804 g
10.59 lb
For more information contact us:
info@fastercouplings.com
* This part number is equipped with a shorter lever (R250 mm instead of R318 mm)
6
6
Male
Filter items
Units
Metric
Imperial
Size (mm)
12.5 mm
Size (mm)
Size (mm)
12.5 mm
Size (in)
1/2"
Size (in)
Size (in)
1/2"
PartNumber
Specs
Housings
Couplings
Electrical Contacts
12,5
1/2"
|1/2|
2P608-2-4-12GMC
Specs
4 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :
3 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
4
2
12,5
1/2"
|1/2|
2P608-4-11/GSMC
Specs
4 x Couplings 1/2":
1"-14 UNS MALE ORFS - ISO 8434-3
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2102 g
4.63 lb
For more information contact us:
info@fastercouplings.com
6
4
12,5
1/2"
|1/2|
2P608-4-12S M C
Specs
4 x Couplings 1/2":
3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2187 g
4.82 lb
For more information contact us:
info@fastercouplings.com
6
4
12,5
1/2"
|1/2|
2P608-4-8B M C
Specs
4 x Couplings 1/2":
13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2039.4 g
4.5 lb
For more information contact us:
info@fastercouplings.com
6
4
12,5
1/2"
|1/2|
2P608-5-12G M C
Specs
5 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
5
12,5
1/2"
|1/2|
2P608-6-12G M C
Specs
6 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2630 g
5.8 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-12S M C
Specs
6 x Couplings 1/2":
3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2625 g
5.79 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-13/FSMC
Specs
6 x Couplings 1/2":
3/4"-16 UNF MALE JIC - ISO 8434-2
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-34S M C
Specs
6 x Couplings 1/2":
1 - 1/16" - 12 UN FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2776.9 g
6.12 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
2P608-6-8B M C
Specs
6 x Couplings 1/2":
13/16"-16 UN MALE ORFS - ISO 8434-3
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
2460.3 g
5.42 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
3P608-1-5-12GMC
Specs
5 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :
3 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
5
1
12,5
1/2"
|1/2|
3P608-6-12G M C
Specs
6 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
Weight:
3181 g
7.01 lb
For more information contact us:
info@fastercouplings.com
6
6
12,5
1/2"
|1/2|
3P608-6-12S M C
Specs
6 x Couplings 1/2":
3/4" - 16 UNF FEMALE ORB - ISO 11926-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
Seals:
NBR & PUR
Weight:
4221 g
9.31 lb
6
6
12,5
1/2"
|1/2|
3P608-A-5-12GMC
Specs
5 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
1 Electrical Contact :
7 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
5
1
12,5
1/2"
|1/2|
3P608-B-4-12GMC
Specs
4 x Couplings 1/2":
BSPP 1/2" FEMALE - ISO 1179-1
Flow Rate:
70 (l/min) at 0.2 MPa
18.492 (gal/min) at 0.2 MPa
2 Electrical Contacts :
7 Pins
Temperature:
-25 °C to 100 °C
-13 °F to 212 °F
Seals:
NBR & PUR
For more information contact us:
info@fastercouplings.com
6
4
2
Tractor Front Loaders (3 Functions)
Tractor Front Loaders (2 Functions)
Technical Specifications
Burst pressure (MPa)
Burst pressure (psi)
Dash Size
Size (
mm
Inch
)
Working Pressure
Flow Rate (
l/min
gal/min
)
Spillage (ml)
Male
Burst pressure
Female
Burst pressure
Male + Female
Burst pressure
08
12.5
1/2"
25 MPa
3625.943 psi
70
18.492
0.01
100 MPa
100
14503.774 psi
14503.774
100 MPa
100
14503.774 psi
14503.774
100 MPa
100
14503.774 psi
14503.774
Material:
Aluminium & Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C
-13 °F to 212 °F
Surface treatment:
MATE 500 (CrIII) & Paint
Warnings:
This product can expose you to chemicals such as Lead or Nickel which are known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to
www.p65warnings.ca.gov
.
Specifications:
Series Interchange: MultiFaster
Valve Type: Flat
Connection: Lever
Disconnection: Lever
Connection Under Pressure: Allowed Residual
