Product series
FFH
Applications
Construction Equipment Industrial Oil&Gas Vehicles & Road Machines Mining

Flat face couplings, ISO 16028 interchange, 35 MPa series

Flat-Face couplings with real maximum working pressure of 35 MPa and Zinc-Nickel plating. Flat valve shut-off system contributes to prevent contamination and spillage. ISO 16028 interchange (except for 1/8" and 1-1/4”).
Downloads
Female

Female

Filter items
Units
PartNumber Thread Details HEX1 HEX2 HEX3 D1 D3 L1
3,2 1/8" FFH02 14GAS F BSPP 1/4" FEMALE
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
18 0.71 20 0.79 2.02 51.3
3,2 1/8" FFH02 18GAS F BSPP 1/8" FEMALE
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 78 g 0.17 lb
18 0.71 20 0.79 1.81 46.1
3,2 1/8" FFH02-13/14S F 7/16"-20 UNF MALE JIC
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 87.2 g 0.19 lb
18 0.71 20 0.79 2.37 60.1
6,3 1/4" FFH04 14GAS F BSPP 1/4" FEMALE
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 175.1 g 0.39 lb
24 0.94 27 1.06 2.32 58.9
6,3 1/4" FFH04 14JPT F RC 1/4 FEMALE (JPT)
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 175 g 0.39 lb
24 0.94 27 1.06 2.32 58.9
6,3 1/4" FFH04 14NPT F NPTF 1/4" FEMALE
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 175.9 g 0.39 lb
24 0.94 27 1.06 2.32 58.9
6,3 1/4" FFH04 14SAE F 7/16"-20 UNF FEMALE ORB
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
24 0.94 27 1.06 2.32 59
6,3 1/4" FFH04 38SAE F 9/16"-18 UNF FEMALE ORB
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 172.3 g 0.38 lb
24 0.94 27 1.06 2.35 59.6
6,3 1/4" FFH04-0/1615 F M16x1,5 FEMALE ORB
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 172 g 0.38 lb
24 0.94 27 1.06 2.41 61.1
6,3 1/4" FFH04-1/1415 F M14x1,5 MALE
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 185 g 0.41 lb
24 0.94 27 1.06 2.8 71
6,3 1/4" FFH04-11/38S F 11/16"-16 UN MALE ORFS
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 190 g 0.42 lb
24 0.94 27 1.06 2.7 68.5
6,3 1/4" FFH04-12/38S F 11/16"-16 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 239.4 g 0.53 lb
24 0.94 25 0.98 27 1.06 3.6 91.4
6,3 1/4" FFH04-12/38SFD 11/16"-16 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 220.6 g 0.49 lb
* The bulkhead end diesn't include the nut fir installation
24 0.94 25 0.98 27 1.06 3.6 91.4
6,3 1/4" FFH04-13/38S F 9/16"-18 UNF MALE JIC
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 184 g 0.41 lb
24 0.94 27 1.06 2.81 71.5
6,3 1/4" FFH04-14/38S F 9/16"-18 UNF MALE BULKHEAD JIC
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 213 g 0.47 lb
24 0.94 22 0.87 27 1.06 3.54 89.9
6,3 1/4" FFH04-2/1415 F M14x1,5 MALE 8L
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 182 g 0.4 lb
24 0.94 27 1.06 2.65 67.4
6,3 1/4" FFH04-2/1615 F M16x1,5 MALE 10L
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
24 0.94 27 1.06 2.69 68.4
6,3 1/4" FFH04-5/1615 F M16x1,5 MALE BULKHEAD 10L
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
24 0.94 27 1.06 3.64 92.4
6,3 1/4" FFH04-7/1615 F M16x1,5 MALE BULKHEAD SHORT 10L
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 203.6 g 0.45 lb
24 0.94 22 0.87 27 1.06 3.24 82.4
10 3/8" FFH06 12GAS F BSPP 1/2" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 263.6 g 0.58 lb
27 1.06 30 1.18 3.13 79.4
10 3/8" FFH06 12JPT F RC 1/2 FEMALE (JPT)
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
27 1.06 27 1.06 30 1.18 3.09 78.4
10 3/8" FFH06 12NPT F NPTF 1/2" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 264.1 g 0.58 lb
27 1.06 30 1.18 3.13 79.4
10 3/8" FFH06 12SAE F 3/4"-16 UNF FEMALE ORB
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 261 g 0.58 lb
27 1.06 30 1.18 3.03 76.9
10 3/8" FFH06 38GAS F BSPP 3/8" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 267.7 g 0.59 lb
27 1.06 30 1.18 2.95 75
10 3/8" FFH06 38GAS FB BSPP 3/8" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -40 °C to 90 °C -40 °F to 194 °F
Seals: NBR & PUR
27 1.06 27 1.06 30 1.18 2.95 75
10 3/8" FFH06 38GAS FV BSPP 3/8" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -20 °C to 200 °C -4 °F to 392 °F
Seals: FKM
Weight: 268 g 0.59 lb
27 1.06 30 1.18 2.95 75
10 3/8" FFH06 38JPT F RC 3/8 FEMALE (JPT)
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
27 1.06 27 1.06 30 1.18 2.95 74.9
10 3/8" FFH06 38NPT F NPTF 3/8" FEMALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 265.6 g 0.59 lb
27 1.06 30 1.18 2.95 75
10 3/8" FFH06 38SAE F 9/16" - 18 UNF FEMALE ORB
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 270 g 0.6 lb
27 1.06 30 1.18 2.95 75
10 3/8" FFH06-1/12S F 3/4"-16 UNF MALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 272.8 g 0.6 lb
27 1.06 30 1.18 3.18 80.7
10 3/8" FFH06-1/38S F 9/16"-18 UNF MALE
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 264.1 g 0.58 lb
27 1.06 30 1.18 3.15 79.9
10 3/8" FFH06-12/12S F 13/16"-16 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 342.9 g 0.76 lb
27 1.06 27 1.06 30 1.18 4.17 106
10 3/8" FFH06-14/12S F 3/4"-16 UN MALE BULKHEAD JIC
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 319.6 g 0.7 lb
27 1.06 27 1.06 30 1.18 4.19 106.5
10 3/8" FFH06-2/1615 F M16x1,5 MALE 10L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 269 g 0.59 lb
27 1.06 30 1.18 3.19 80.9
10 3/8" FFH06-2/1815 F M18x1,5 MALE 12L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 206 g 0.45 lb
27 1.06 30 1.18 3.19 80.9
10 3/8" FFH06-2/2215 F M22x1,5 MALE 15L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 271.2 g 0.6 lb
27 1.06 30 1.18 3.22 81.9
10 3/8" FFH06-27/12S F 13/16" - 16 UN SAE FEMALE ORFS
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 270 g 0.6 lb
27 1.06 30 1.18 3.11 79
10 3/8" FFH06-27/58S F 1" - 14 UNS SAE FEMALE ORFS
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 320 g 0.71 lb
32 1.26 30 1.18 3.11 79
10 3/8" FFH06-3/2015 F M20x1.5 MALE 12S
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 282 g 0.62 lb
27 1.06 30 1.18 3.19 80.9
10 3/8" FFH06-5/1815 F M18x1,5 MALE BULKHEAD 12L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 307 g 0.68 lb
27 1.06 24 0.94 30 1.18 4.17 105.9
10 3/8" FFH06-7/1615 F M16x1,5 MALE BULKHEAD SHORT 10L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
27 1.06 22 0.87 30 1.18 3.74 94.9
10 3/8" FFH06-7/1815 F M18x1.5 MALE BULKHEAD SHORT 12L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 294 g 0.65 lb
27 1.06 24 0.94 30 1.18 3.78 95.9
10 3/8" FFH06-7/2215 F M22x1.5 MALE BULKHEAD SHORT 15L
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 311.2 g 0.69 lb
27 1.06 27 1.06 30 1.18 3.85 97.9
12,5 1/2" FFH08 12GAS F BSPP 1/2" FEMALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 458.3 g 1.01 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08 12GAS FV BSPP 1/2" FEMALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -20 °C to 200 °C -4 °F to 392 °F
Seals: FKM
Weight: 460 g 1.01 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08 12JPT F RC 1/2 FEMALE (JPT)
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
34 1.34 38 1.5 37 1.46 3.2 81.3
12,5 1/2" FFH08 12NPT F NPTF 1/2" FEMALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 464.9 g 1.02 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08 12SAE F 3/4"-16 UNF FEMALE ORB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 468 g 1.03 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08 34GAS F BSPP 3/4" FEMALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 446.3 g 0.98 lb
34 1.34 38 1.5 3.34 84.8
12,5 1/2" FFH08 34NPT F NPTF 3/4" FEMALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 446.3 g 0.98 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08 34SAE F 1-1/16"-12 UN FEMALE ORB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 448.4 g 0.99 lb
34 1.34 38 1.5 3.42 86.8
12,5 1/2" FFH08 34SAE FA 1 - 1/16" - 12 UN FEMALE ORB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 445.6 g 0.98 lb
* This item isn’t equipped with the two lateral safety lock balls
34 1.34 38 1.5 3.42 86.8
12,5 1/2" FFH08 58SAE F 7/8"-14 UNF FEMALE ORB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 452.4 g 1 lb
34 1.34 38 1.5 3.2 81.3
12,5 1/2" FFH08-1/12S F 3/4"-16 UNF MALE
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 434.6 g 0.96 lb
34 1.34 38 1.5 3.24 82.4
12,5 1/2" FFH08-12/12S F 13/16"-16 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 504 g 1.11 lb
34 1.34 27 1.06 38 1.5 4.24 107.8
12,5 1/2" FFH08-12/1SFD 1 7/16" - 12 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 720 g 1.59 lb
* The bulkhead end doesn't include the nut for installation
38 1.5 38 1.5 4.85 123.3
12,5 1/2" FFH08-12/34S F 1-3/16"-12 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 623.5 g 1.37 lb
36 1.42 38 1.5 38 1.5 4.44 112.8
12,5 1/2" FFH08-12/58S F 1"-14 UNS MALE BULKHEAD ORFS
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 564 g 1.24 lb
34 1.34 34 1.34 38 1.5 4.4 111.8
12,5 1/2" FFH08-13/58S F 7/8"-14 UNF MALE JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 448 g 0.99 lb
34 1.34 38 1.5 3.57 90.6
12,5 1/2" FFH08-14/12S F 3/4"-16 UN MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 481 g 1.06 lb
34 1.34 27 1.06 38 1.5 4.25 107.9
12,5 1/2" FFH08-14/12S FS 3/4"-16 UN MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 467.3 g 1.03 lb
* The bulkhead end doesn't include the nut for installation
34 1.34 38 1.5 4.25 107.9
12,5 1/2" FFH08-14/34S F 1-1/16"-12 UN MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 558.4 g 1.23 lb
34 1.34 34 1.34 38 1.5 4.56 115.7
12,5 1/2" FFH08-14/34S FA 1-1/16"-12 UN MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 560.2 g 1.24 lb
* This item isn’t equipped with the two lateral safety lock balls
34 1.34 34 1.34 38 1.5 4.56 115.7
12,5 1/2" FFH08-14/34S FS 1-1/16"-12 UN MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 517 g 1.14 lb
* The bulkhead end doesn't include the nut for installation
34 1.34 38 1.5 4.56 115.7
12,5 1/2" FFH08-14/58S F 7/8"-14 UNF MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 507.5 g 1.12 lb
34 1.34 27 1.06 38 1.5 4.39 111.4
12,5 1/2" FFH08-14/58S FA 7/8"-14 UNF MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 510.6 g 1.13 lb
* This item isn’t equipped with the two lateral safety lock balls
34 1.34 27 1.06 38 1.5 4.39 111.4
12,5 1/2" FFH08-14/58S FS 7/8"-14 UNF MALE BULKHEAD JIC
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 484 g 1.07 lb
* The bulkhead end doesn't include the nut for installation
34 1.34 38 1.5 4.39 111.4
12,5 1/2" FFH08-16/12G F 60° 1/2 BSPP MALE 60° CONE MALE THREAD
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 441 g 0.97 lb
34 1.34 38 1.5 3.35 85
12,5 1/2" FFH08-2/1815 F M18x1,5 MALE 12L
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 432 g 0.95 lb
34 1.34 38 1.5 3.24 82.3
12,5 1/2" FFH08-2/2215 F M22x1,5 MALE 15L
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 442.5 g 0.98 lb
34 1.34 38 1.5 3.28 83.3
12,5 1/2" FFH08-2/2615 F M26x1,5 MALE 18L
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
34 1.34 38 1.5 37 1.46 3.28 83.3
12,5 1/2" FFH08-6/2415 F M24x1.5 MALE BULKHEAD 16S
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 350 g 0.77 lb
34 1.34 30 1.18 38 1.5 4.38 111.3
12,5 1/2" FFH08-6/3020 F M30x2 MALE BULKHEAD 20S
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 470 g 1.04 lb
34 1.34 41 1.61 38 1.5 4.57 116
12,5 1/2" FFH08-7/2215 F M22x1.5 MALE BULKHEAD SHORT 15L
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 479.5 g 1.06 lb
34 1.34 27 1.06 38 1.5 3.91 99.3
12,5 1/2" FFH08-7/2615 F M26x1.5 MALE BULKHEAD SHORT 18L
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 530 g 1.17 lb
34 1.34 36 1.42 38 1.5 3.98 101
16 5/8" FFH10 34GAS F BSPP 3/4" FEMALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 658.6 g 1.45 lb
38 1.5 42 1.65 3.63 92.1
16 5/8" FFH10 34NPT F NPTF 3/4" FEMALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 658.6 g 1.45 lb
38 1.5 42 1.65 3.63 92.1
16 5/8" FFH10 34SAE F 1-1/16"-12 UN FEMALE ORB
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 657.8 g 1.45 lb
38 1.5 42 1.65 3.74 95.1
16 5/8" FFH10 58GAS F BSPP 5/8" FEMALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 664.7 g 1.47 lb
38 1.5 42 1.65 3.59 91.1
16 5/8" FFH10-1/34S F 1-1/16"-12 UN MALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
38 1.5 42 1.65 3.76 95.4
16 5/8" FFH10-1/34S FA 1-1/16"-12 UN MALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 638.7 g 1.41 lb
* This item isn’t equipped with the two lateral safety lock balls
38 1.5 42 1.65 3.76 95.4
16 5/8" FFH10-1/58S F 7/8"-14 UNF MALE
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 624.2 g 1.38 lb
38 1.5 42 1.65 3.66 93
16 5/8" FFH10-14/34S FA 1-1/16"-12 UN MALE BULKHEAD JIC
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 739 g 1.63 lb
* This item isn’t equipped with the two lateral safety lock balls
38 1.5 34 1.34 42 1.65 4.91 124.7
16 5/8" FFH10-2/2615 F M26x1,5 MALE 18L
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
38 1.5 42 1.65 3.63 92.3
16 5/8" FFH10-5/2615 F M26x1,5 MALE BULKHEAD 18L
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 732 g 1.61 lb
38 1.5 36 1.42 42 1.65 4.74 120.3
19 3/4" FFH12 1GAS F BSPP 1" FEMALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 880.6 g 1.94 lb
42 1.65 48 1.89 4.11 104.3
19 3/4" FFH12 1NPT F NPTF 1" FEMALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 880.6 g 1.94 lb
42 1.65 48 1.89 4.11 104.3
19 3/4" FFH12 1SAE F 1-5/16"-12 UN FEMALE ORB
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 874.7 g 1.93 lb
42 1.65 48 1.89 4.11 104.3
19 3/4" FFH12 34GAS F BSPP 3/4" FEMALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 907.1 g 2 lb
42 1.65 48 1.89 3.95 100.3
19 3/4" FFH12 34JPT F RC 3/4 FEMALE (JPT)
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Seals: NBR & PUR
42 1.65 48 1.89 3.95 100.3
19 3/4" FFH12 34NPT F NPTF 3/4" FEMALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 913.5 g 2.01 lb
42 1.65 48 1.89 3.95 100.3
19 3/4" FFH12 34SAE F 1-1/16"-12 UN FEMALE ORB
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 932.4 g 2.06 lb
42 1.65 48 1.89 4.11 104.3
19 3/4" FFH12-0/3320 F M33x2 FEMALE ORB
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 865 g 1.91 lb
42 1.65 48 1.89 4.04 102.6
19 3/4" FFH12-1/2720 F M27x2 MALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 927 g 2.04 lb
42 1.65 48 1.89 4.45 113.1
19 3/4" FFH12-1/2720 FC M27x2 MALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 955.8 g 2.11 lb
* This item is equipped with a front vinyl cap to protect it from dust during storage
42 1.65 48 1.89 4.45 113.1
19 3/4" FFH12-1/34S F 1-1/16"-12 UN MALE
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 900 g 1.98 lb
42 1.65 48 1.89 4.24 107.6
19 3/4" FFH12-12/1S F 1-7/16"-12 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1134 g 2.5 lb
42 1.65 45 1.77 48 1.89 5.27 133.9
19 3/4" FFH12-12/34S F 1-3/16"-12 UN MALE BULKHEAD ORFS
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1068.8 g 2.36 lb
42 1.65 38 1.5 48 1.89 5.25 133.4
19 3/4" FFH12-13/34S FS 1-1/16"-12 UN MALE JIC
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 847 g 1.87 lb
42 1.65 48 1.89 4.2 106.8
19 3/4" FFH12-14/34S F 1-1/16"-12 UN MALE BULKHEAD JIC
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1020.3 g 2.25 lb
42 1.65 34 1.34 48 1.89 5.37 136.3
19 3/4" FFH12-27/1S F 1 - 7/16" - 12 UN SAE FEMALE ORFS
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 900 g 1.98 lb
46 1.81 48 1.89 4.09 104
19 3/4" FFH12-5/3020 F M30x2 MALE BULKHEAD 22L
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
42 1.65 41 1.61 48 1.89 5.27 133.9
19 3/4" FFH12-6/3620 F M36x2 MALE BULKHEAD 25S
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1132 g 2.5 lb
42 1.65 46 1.81 48 1.89 5.47 138.9
25 1" FFH16 112GAS F BSPP 1-1/2" FEMALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1150 g 2.54 lb
55 2.17 55 2.17 4.15 105.3
25 1" FFH16 114GAS F BSPP 1-1/4" FEMALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1110.5 g 2.45 lb
50 1.97 55 2.17 4.06 103
25 1" FFH16 114NPT F NPTF 1-1/4" FEMALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1110.5 g 2.45 lb
50 1.97 55 2.17 3.96 100.5
25 1" FFH16 1GAS F BSPP 1" FEMALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1203 g 2.65 lb
50 1.97 55 2.17 3.96 100.5
25 1" FFH16 1NPT F NPTF 1" FEMALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1212.2 g 2.67 lb
50 1.97 55 2.17 3.96 100.5
25 1" FFH16 1SAE F 1-5/16"-12 UN FEMALE ORB
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
50 1.97 55 2.17 3.96 100.5
25 1" FFH16-0/3320 F M33x2 FEMALE ORB
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
50 1.97 55 2.17 4.06 103
25 1" FFH16-1/3020 F M30x2 MALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
50 1.97 55 2.17 4.78 121.5
25 1" FFH16-1/3020 FC M30x2 MALE
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1400.5 g 3.09 lb
* This item is equipped with a front vynile cap to protect it from dust during storage
50 1.97 55 2.17 4.78 121.5
25 1" FFH16-6/3620 F M36x2 MALE BULKHEAD 25S
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1463 g 3.23 lb
50 1.97 46 1.81 55 2.17 5.55 141
31,5 1-1/4" FFH20 114GAS F BSPP 1-1/4" FEMALE
Specs
Flow Rate: 390 (l/min) at 0.2 MPa 103.027 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1606 g 3.54 lb
60 2.36 63 2.48 64 2.52 4.07 103.4
31,5 1-1/4" FFH20 114NPT F NPTF 1-1/4" FEMALE
Specs
Flow Rate: 390 (l/min) at 0.2 MPa 103.027 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1606 g 3.54 lb
60 2.36 63 2.48 4.07 103.4
Male

Male

Filter items
Units
PartNumber Thread Specs HEX1 HEX2 D1 D3 L1
3,2 1/8" FFH02 18GAS M
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 45.7 g 0.1 lb
16 0.63 18 0.71 11.6 0.46 1.73 44
3,2 1/8" FFH02-1/38S M
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 60.4 g 0.13 lb
17 0.67 19 0.75 11.6 0.46 2.13 54
3,2 1/8" FFH02-21/14G M
Specs
Flow Rate: 12 (l/min) at 0.2 MPa 3.17 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
19 0.75 21 0.83 11.6 0.46 2.01 51
6,3 1/4" FFH04 14GAS M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 101.1 g 0.22 lb
24 0.94 26 1.02 16.1 0.63 1.93 49
6,3 1/4" FFH04 14JPT M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 101 g 0.22 lb
24 0.94 26 1.02 1.93 49
6,3 1/4" FFH04 14NPT M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 101.1 g 0.22 lb
24 0.94 26 1.02 16.1 0.63 1.93 49
6,3 1/4" FFH04 14SAE M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 105 g 0.23 lb
24 0.94 26 1.02 16.1 0.63 1.93 49
6,3 1/4" FFH04 38SAE M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 105.8 g 0.23 lb
24 0.94 26 1.02 16.1 0.63 2.05 52
6,3 1/4" FFH04-1/1415 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 110 g 0.24 lb
26 1.02 26 1.02 16.1 0.63 2.09 53
6,3 1/4" FFH04-1/14G M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 109.8 g 0.24 lb
24 0.94 26 1.02 16.1 0.63 2.05 52
6,3 1/4" FFH04-11/38S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 85 g 0.19 lb
24 0.94 26 1.02 16.1 0.63 1.99 50.5
6,3 1/4" FFH04-12/38S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 140.7 g 0.31 lb
24 0.94 25 0.98 26 1.02 16.1 0.63 2.89 73.5
6,3 1/4" FFH04-12/38SMB
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 121.3 g 0.27 lb
24 0.94 26 1.02 16.1 0.63 2.89 73.5
6,3 1/4" FFH04-13/38S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 83 g 0.18 lb
24 0.94 26 1.02 16.1 0.63 2.11 53.6
6,3 1/4" FFH04-14/38S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 111 g 0.24 lb
24 0.94 22 0.87 26 1.02 16.1 0.63 2.83 72
6,3 1/4" FFH04-2/1415 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 100 g 0.22 lb
24 0.94 26 1.02 16.1 0.63 1.97 50
6,3 1/4" FFH04-27/38S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Seals: NBR & PUR
24 0.94 24 0.94 26 1.02 1.97 50
6,3 1/4" FFH04-28/12S M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 90 g 0.2 lb
24 0.94 26 1.02 16.1 0.63 1.97 50
6,3 1/4" FFH04-3/1615 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
24 0.94 26 1.02 16.1 0.63 2.03 51.5
6,3 1/4" FFH04-5/1615 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 115 g 0.25 lb
24 0.94 22 0.87 26 1.02 16.1 0.63 2.93 74.5
6,3 1/4" FFH04-6/1615 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
24 0.94 22 0.87 26 1.02 16.1 0.63 2.97 75.5
6,3 1/4" FFH04-7/1415 M
Specs
Flow Rate: 25 (l/min) at 0.2 MPa 6.604 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 100 g 0.22 lb
24 0.94 19 0.75 26 1.02 16.1 0.63 2.5 63.5
10 3/8" FFH06 12GAS M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 236.2 g 0.52 lb
30 1.18 33 1.3 19.7 0.78 2.89 73.3
10 3/8" FFH06 12JPT M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
30 1.18 30 1.18 33 1.3 2.83 71.8
10 3/8" FFH06 12NPT M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 236.2 g 0.52 lb
30 1.18 33 1.3 19.7 0.78 2.83 71.8
10 3/8" FFH06 12SAE M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 235.6 g 0.52 lb
30 1.18 33 1.3 19.7 0.78 2.83 71.8
10 3/8" FFH06 38GAS M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 230.8 g 0.51 lb
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06 38GAS MB
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -40 °C to 90 °C -40 °F to 194 °F
Seals: NBR & PUR
30 1.18 30 1.18 33 1.3 2.69 68.3
10 3/8" FFH06 38GAS MR
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 191 g 0.42 lb
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06 38GAS MV
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -20 °C to 200 °C -4 °F to 392 °F
Seals: FKM
Weight: 227 g 0.5 lb
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06 38JPT M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
30 1.18 33 1.3 2.69 68.3
10 3/8" FFH06 38NPT M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 232.6 g 0.51 lb
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06 38NPT MT
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
* Supplied with orange cap in PVC (PN: TFF 38)
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06 38SAE M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 230 g 0.51 lb
30 1.18 33 1.3 19.7 0.78 2.69 68.3
10 3/8" FFH06-0/1815 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 230 g 0.51 lb
30 1.18 33 1.3 19.7 0.78 2.8 71
10 3/8" FFH06-1/12G M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 224.8 g 0.5 lb
30 1.18 33 1.3 19.7 0.78 2.98 75.8
10 3/8" FFH06-1/12S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 221.4 g 0.49 lb
30 1.18 33 1.3 19.7 0.78 2.85 72.4
10 3/8" FFH06-11/12S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 229.4 g 0.51 lb
30 1.18 33 1.3 19.7 0.78 2.91 74
10 3/8" FFH06-11/38S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 220 g 0.49 lb
30 1.18 33 1.3 19.7 0.78 2.85 72.3
10 3/8" FFH06-12/12S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 291.2 g 0.64 lb
30 1.18 27 1.06 33 1.3 19.7 0.78 3.86 98
10 3/8" FFH06-12/12SMB
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 268.6 g 0.59 lb
* The bulkhead end doesn't include the nut for installation
30 1.18 33 1.3 19.7 0.78 3.86 98
10 3/8" FFH06-14/12S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 266.1 g 0.59 lb
30 1.18 27 1.06 33 1.3 19.7 0.78 3.85 97.9
10 3/8" FFH06-2/1615 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 211 g 0.47 lb
30 1.18 33 1.3 19.7 0.78 2.85 72.3
10 3/8" FFH06-2/1815 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 217 g 0.48 lb
30 1.18 33 1.3 19.7 0.78 2.85 72.3
10 3/8" FFH06-2/2215 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 221.8 g 0.49 lb
30 1.18 33 1.3 19.7 0.78 2.89 73.3
10 3/8" FFH06-21/12G M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 216 g 0.48 lb
30 1.18 33 1.3 19.7 0.78 2.96 75.3
10 3/8" FFH06-27/12S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 235 g 0.52 lb
30 1.18 33 1.3 19.7 0.78 2.89 73.3
10 3/8" FFH06-27/58S M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 250 g 0.55 lb
32 1.26 35 1.38 19.7 0.78 2.89 73.3
10 3/8" FFH06-3/2015 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
30 1.18 33 1.3 19.7 0.78 2.89 73.3
10 3/8" FFH06-5/1815 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 252 g 0.56 lb
30 1.18 24 0.94 33 1.3 19.7 0.78 3.83 97.3
10 3/8" FFH06-7/1815 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 245.3 g 0.54 lb
30 1.18 24 0.94 33 1.3 19.7 0.78 3.44 87.3
10 3/8" FFH06-7/1815 MT
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
* Supplied with orange PVC cap (PN: TFF 38)
30 1.18 24 0.94 33 1.3 19.7 0.78 3.44 87.3
10 3/8" FFH06-7/2215 M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 263.5 g 0.58 lb
30 1.18 27 1.06 33 1.3 19.7 0.78 3.52 89.3
10 3/8" FFH06-7/2215 MT
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Seals: NBR & PUR
* Supplied with orange PVC cap (PN: TFF 38).
30 1.18 27 1.06 33 1.3 19.7 0.78 3.52 89.3
10 3/8" FFH06-77/12G M
Specs
Flow Rate: 50 (l/min) at 0.2 MPa 13.209 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 210.3 g 0.46 lb
30 1.18 33 1.3 19.7 0.78 2.87 72.8
12,5 1/2" 3FFH08-2/2215 M
Specs
Flow Rate: 65 (l/min) at 0.2 MPa 17.171 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 424 g 0.93 lb
34 1.34 37 1.46 24.5 0.96 4.57 116.2
12,5 1/2" FFH08 12GAS M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 333.3 g 0.73 lb
34 1.34 37 1.46 24.5 0.96 2.95 75
12,5 1/2" FFH08 12GAS MV
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -20 °C to 200 °C -4 °F to 392 °F
Seals: FKM
Weight: 333.3 g 0.73 lb
34 1.34 37 1.46 24.5 0.96 2.95 75
12,5 1/2" FFH08 12JPT M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
34 1.34 37 1.46 3.03 77
12,5 1/2" FFH08 12NPT M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 333.3 g 0.73 lb
34 1.34 37 1.46 24.5 0.96 3.03 77
12,5 1/2" FFH08 12NPT MT
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
* Supplied with orange PVC cap (PN: TF 2FI12).
34 1.34 37 1.46 24.5 0.96 3.03 77
12,5 1/2" FFH08 12SAE M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 325.8 g 0.72 lb
34 1.34 37 1.46 24.5 0.96 2.95 75
12,5 1/2" FFH08 34GAS M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 445.7 g 0.98 lb
34 1.34 37 1.46 24.5 0.96 3.07 78
12,5 1/2" FFH08 34NPT M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 445.7 g 0.98 lb
34 1.34 37 1.46 24.5 0.96 3.03 77
12,5 1/2" FFH08 34SAE M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 308.1 g 0.68 lb
34 1.34 37 1.46 24.5 0.96 3.19 81
12,5 1/2" FFH08 58SAE M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 315.4 g 0.7 lb
34 1.34 37 1.46 24.5 0.96 2.99 76
12,5 1/2" FFH08-0/2720 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 308 g 0.68 lb
34 1.34 37 1.46 24.5 0.96 3.19 81
12,5 1/2" FFH08-1/12G M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
34 1.34 37 1.46 24.5 0.96 3.07 78
12,5 1/2" FFH08-1/12S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 277.5 g 0.61 lb
34 1.34 37 1.46 24.5 0.96 2.94 74.6
12,5 1/2" FFH08-1/2215 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 285 g 0.63 lb
34 1.34 37 1.46 24.5 0.96 3.09 78.5
12,5 1/2" FFH08-12/12S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 354.7 g 0.78 lb
34 1.34 27 1.06 37 1.46 24.5 0.96 3.94 100
12,5 1/2" FFH08-12/1SMB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 312 g 0.69 lb
34 1.34 42 1.65 24.5 0.96 4.45 113
12,5 1/2" FFH08-12/34S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 459 g 1.01 lb
34 1.34 38 1.5 37 1.46 24.5 0.96 4.15 105.5
12,5 1/2" FFH08-12/58S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 412.7 g 0.91 lb
34 1.34 34 1.34 37 1.46 24.5 0.96 4.09 104
12,5 1/2" FFH08-12/58SMB
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 371.5 g 0.82 lb
34 1.34 37 1.46 24.5 0.96 4.09 104
12,5 1/2" FFH08-13/58S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 298 g 0.66 lb
34 1.34 37 1.46 24.5 0.96 3.26 82.8
12,5 1/2" FFH08-14/34S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 407.5 g 0.9 lb
34 1.34 34 1.34 37 1.46 24.5 0.96 4.27 108.4
12,5 1/2" FFH08-14/58S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 355.3 g 0.78 lb
34 1.34 27 1.06 37 1.46 24.5 0.96 4.08 103.6
12,5 1/2" FFH08-16/12G M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 290 g 0.64 lb
34 1.34 37 1.46 24.5 0.96 3.05 77.5
12,5 1/2" FFH08-2/1815 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
34 1.34 37 1.46 24.5 0.96 2.93 74.5
12,5 1/2" FFH08-2/2215 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 286 g 0.63 lb
34 1.34 37 1.46 24.5 0.96 2.97 75.5
12,5 1/2" FFH08-5/1815 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
34 1.34 24 0.94 37 1.46 24.5 0.96 3.92 99.5
12,5 1/2" FFH08-6/2415 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 320 g 0.71 lb
34 1.34 37 1.46 24.5 0.96 4.07 103.5
12,5 1/2" FFH08-61/34S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 494.5 g 1.09 lb
34 1.34 38 1.5 24.5 0.96 3.5 89
12,5 1/2" FFH08-61/38S M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 481 g 1.06 lb
34 1.34 38 1.5 24.5 0.96 3.5 89
12,5 1/2" FFH08-7/2215 M
Specs
Flow Rate: 110 (l/min) at 0.2 MPa 29.059 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 325.7 g 0.72 lb
34 1.34 37 1.46 24.5 0.96 3.6 91.5
16 5/8" FFH10 34GAS M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 545.7 g 1.2 lb
41 1.61 45 1.77 27 1.06 3.59 91.1
16 5/8" FFH10 34NPT M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 551.2 g 1.22 lb
41 1.61 45 1.77 27 1.06 3.59 91.1
16 5/8" FFH10 34SAE M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 561.3 g 1.24 lb
41 1.61 45 1.77 27 1.06 3.7 94.1
16 5/8" FFH10 58GAS M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 568.6 g 1.25 lb
41 1.61 45 1.77 27 1.06 3.59 91.1
16 5/8" FFH10-1/34S M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 477 g 1.05 lb
41 1.61 45 1.77 27 1.06 3.57 90.8
16 5/8" FFH10-1/58S M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 460.7 g 1.02 lb
41 1.61 45 1.77 27 1.06 3.48 88.4
16 5/8" FFH10-2/2615 M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 461.2 g 1.02 lb
41 1.61 45 1.77 27 1.06 3.45 87.7
16 5/8" FFH10-5/2615 M
Specs
Flow Rate: 125 (l/min) at 0.2 MPa 33.022 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 570 g 1.26 lb
41 1.61 36 1.42 45 1.77 27 1.06 4.56 115.7
19 3/4" FFH12 1GAS M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 592.8 g 1.31 lb
42 1.65 46 1.81 29.95 1.18 4 101.6
19 3/4" FFH12 1NPT M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 605.6 g 1.34 lb
42 1.65 46 1.81 29.95 1.18 4 101.5
19 3/4" FFH12 1SAE M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 585.5 g 1.29 lb
42 1.65 46 1.81 29.95 1.18 4 101.6
19 3/4" FFH12 34GAS M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 645.6 g 1.42 lb
42 1.65 46 1.81 29.95 1.18 4 101.6
19 3/4" FFH12 34JPT M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Seals: NBR & PUR
42 1.65 46 1.81 4 101.5
19 3/4" FFH12 34NPT M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 653.2 g 1.44 lb
42 1.65 46 1.81 29.95 1.18 4 101.6
19 3/4" FFH12 34SAE M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 639.9 g 1.41 lb
42 1.65 46 1.81 29.95 1.18 4 101.6
19 3/4" FFH12-0/2720 M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 615 g 1.36 lb
42 1.65 46 1.81 29.95 1.18 3.98 101
19 3/4" FFH12-1/34S M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
42 1.65 46 1.81 29.95 1.18 3.98 101
19 3/4" FFH12-12/34S M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 733.3 g 1.62 lb
42 1.65 38 1.5 46 1.81 29.95 1.18 5.02 127.4
19 3/4" FFH12-13/34S M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 576 g 1.27 lb
42 1.65 46 1.81 29.95 1.18 4.24 107.8
19 3/4" FFH12-14/34S M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 666 g 1.47 lb
42 1.65 34 1.34 46 1.81 29.95 1.18 5.13 130.3
19 3/4" FFH12-27/1S M
Specs
Flow Rate: 160 (l/min) at 0.2 MPa 42.268 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 700 g 1.54 lb
46 1.81 50 1.97 29.95 1.18 3.98 101
25 1" FFH16 112GAS M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 902 g 1.99 lb
55 2.17 59 2.32 36 1.42 4.33 110
25 1" FFH16 114GAS M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 995 g 2.19 lb
55 2.17 59 2.32 36 1.42 4.29 109
25 1" FFH16 114NPT M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 976 g 2.15 lb
55 2.17 59 2.32 36 1.42 4.19 106.5
25 1" FFH16 1GAS M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1064 g 2.35 lb
55 2.17 59 2.32 36 1.42 4.19 106.5
25 1" FFH16 1NPT M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1088 g 2.4 lb
55 2.17 59 2.32 36 1.42 4.23 107.5
25 1" FFH16 1SAE M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1055 g 2.33 lb
55 2.17 59 2.32 36 1.42 4.19 106.5
25 1" FFH16-12/1S M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1200 g 2.65 lb
55 2.17 45 1.77 59 2.32 36 1.42 5.31 135
25 1" FFH16-14/114S M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1183 g 2.61 lb
55 2.17 50 1.97 59 2.32 36 1.42 5.47 139
25 1" FFH16-6/3620 M
Specs
Flow Rate: 230 (l/min) at 0.2 MPa 60.76 (gal/min) at 0.2 MPa
Temperature: -25 °C to 100 °C -13 °F to 212 °F
Seals: NBR & PUR
Weight: 1158 g 2.55 lb
55 2.17 46 1.81 59 2.32 36 1.42 5.51 140
31,5 1-1/4" FFH20 114GAS M
Specs
Flow Rate: 390 (l/min) at 0.2 MPa 103.027 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1112 g 2.45 lb
55 2.17 59 2.32 4.29 109
31,5 1-1/4" FFH20 114NPT M
Specs
Flow Rate: 390 (l/min) at 0.2 MPa 103.027 (gal/min) at 0.2 MPa
Seals: NBR & PUR
Weight: 1112 g 2.45 lb
55 2.17 59 2.32 44 1.73 4.19 106.5
  • Dust Protections
  • Seals for Couplings
  • Various Accessories
  • Seals

Accessories & Spares

Size (mm) Size (in) Thread Part Number Material
12,5 1/2" MF AD 08-NVF-FFHM Steel
12,5 1/2" MF AD 08-FFHF-NVM Steel
Acetal Resin caps female Dust Protection - Acetal Resin - Female
Size Part Number Color
1/2"
12,5 mm
 TA 12
Blue
3/8"
10 mm
 TAF 38
Blue
3/8"
10 mm
 TAF 38 G
Yellow
3/8"
10 mm
 TAF 38 N
Black
3/8"
10 mm
 TAF 38 R
Red
3/8"
10 mm
 TAF 38 V
Green
1/2"
12,5 mm
 TAID 12 N
Black
PVC caps female Dust Protection - PVC - Female
Size Part Number Color
1"
25 mm
 TM 2FI1
Orange
1"
25 mm
 TM 2FI1 N
Black
1/2"
12,5 mm
 TM 2FI12
Orange
1/2"
12,5 mm
 TM 2FI12 N
Black
1/2"
12,5 mm
 TM 2FI12 R
Red
1/4"
6,3 mm
 TM 2FI14
Orange
1/4"
6,3 mm
 TM 2FI14 N
Black
3/4"
19 mm
 TM 2FI34
Orange
3/4"
19 mm
 TM 2FI34 N
Black
3/4"
19 mm
 TM 2FI34 R
Red
5/8"
16 mm
 TM 2FI58
Orange
3/8"
10 mm
 TMF 38
Orange
3/8"
10 mm
 TMF 38 B
Blue
3/8"
10 mm
 TMF 38 G
Yellow
3/8"
10 mm
 TMF 38 N
Black
3/8"
10 mm
 TMF 38 R
Red
3/8"
10 mm
 TMF 38 V
Green
PVC caps male Dust Protection - PVC - Male
Size Part Number Color
1"
25 mm
 TF 2FI1
Orange
1"
25 mm
 TF 2FI1 N
Black
1/2"
12,5 mm
 TF 2FI12
Orange
1/2"
12,5 mm
 TF 2FI12 B
Blue
1/2"
12,5 mm
 TF 2FI12 N
Black
1/2"
12,5 mm
 TF 2FI12 R
Red
1/4"
6,3 mm
 TF 2FI14
Orange
1/4"
6,3 mm
 TF 2FI14 N
Black
3/4"
19 mm
 TF 2FI34
Orange
3/4"
19 mm
 TF 2FI34 N
Black
3/4"
19 mm
 TF 2FI34 R
Red
5/8"
16 mm
 TF 2FI58
Orange
3/8"
10 mm
 TFF 38
Orange
3/8"
10 mm
 TFF 38 B
Blue
3/8"
10 mm
 TFF 38 G
Yellow
3/8"
10 mm
 TFF 38 N
Black
3/8"
10 mm
 TFF 38 R
Red
3/8"
10 mm
 TFF 38 V
Green
Aluminium caps female Dust Protection - Aluminium - Female
Size Part Number Color
1"
25 mm
 TM 2FI1 S
Metal
1/2"
12,5 mm
 TM 2FI12 S
Metal
1/4"
6,3 mm
 TM 2FI14 S
Metal
3/4"
19 mm
 TM 2FI34 S
Metal
3/8"
10 mm
 TM 2FN38 S
Metal
Aluminium caps male Dust Protection - Aluminium - Male
Size Part Number Color
1"
25 mm
 TF 2FI1 S
Metal
1/2"
12,5 mm
 TF 2FI12 S
Metal
1/4"
6,3 mm
 TF 2FI14 S
Metal
3/4"
19 mm
 TF 2FI34 S
Metal
Seal kits
Size Thread Part Number
6,3 mm 1/4" M SK MF 14
3,2 mm 1/8" M SK FFH02
10 mm 3/8" SK FFH06
12,5 mm 1/2" SK FFH08
16 mm 5/8" M SK FFH10
19 mm 3/4" M SK FFH12
25 mm 1" M SK FFH16
10 mm 3/8" M SK FFH06 V
12,5 mm 1/2" M SK FFH08 V
Technical Specifications
Dash Size Size (mmInch) Working Pressure Flow Rate (l/mingal/min) Spillage (ml) Force to connect (N) Male Burst pressure Female Burst pressure Male + Female Burst pressure
02 3.2 1/8" 35 MPa 5076.321 psi 12 3.17 0.001 105 170 MPa 24656.415 psi 140 MPa 20305.283 psi 180 MPa 26106.793 psi
04 6.3 1/4" 35 MPa 5076.321 psi 25 6.604 0.006 110 170 MPa 24656.415 psi 140 MPa 20305.283 psi 180 MPa 26106.793 psi
06 10 3/8" 35 MPa 5076.321 psi 50 13.209 0.008 150 170 MPa 24656.415 psi 140 MPa 20305.283 psi 170 MPa 24656.415 psi
08 12.5 1/2" 35 MPa 5076.321 psi 110 29.059 0.01 210 140 MPa 20305.283 psi 140 MPa 20305.283 psi 170 MPa 24656.415 psi
10 16 5/8" 35 MPa 5076.321 psi 125 33.022 0.02 205 140 MPa 20305.283 psi 140 MPa 20305.283 psi 140 MPa 20305.283 psi
12 19 3/4" 35 MPa 5076.321 psi 160 42.268 0.02 215 140 MPa 20305.283 psi 140 MPa 20305.283 psi 140 MPa 20305.283 psi
16 25 1" 35 MPa 5076.321 psi 230 60.76 0.03 280 140 MPa 20305.283 psi 140 MPa 20305.283 psi 170 MPa 24656.415 psi
20 31.5 1-1/4" 35 MPa 5076.321 psi 390 103.027 0.03 350 105 MPa 15228.962 psi 105 MPa 15228.962 psi 140 MPa 20305.283 psi
Material:
Steel
Seals:
NBR & PUR
Working temperatures:
-25 °C to 100 °C -13 °F to 212 °F
Surface treatment:
MATE 1000 (ZnNi)
Specifications:
Series Interchange: ISO 16028
Valve Type: Flat
Connection: Push to Connect
Disconnection: Sleeve Retraction
Connection Under Pressure: Not Allowed

Exceptions:

Size 1/8" has surface treatment in MATE 500 (CRlll).

Pressure Drop

Data shown in the diagram are indicative and not binding.
(§) 1 MPa = 10 bar
Dash size are specified.

FFH flow diagram
